Valves

Coastal Casting created Coastal Combustion to assure our customers have to best possible material in all of their cylinder heads. Coastal Combustion’s valves are made to exacting standards, and with the best materials in the industry. We feature valves with Stellite 12, much of the industry uses Stellite 6. Our experience is that the 12 handles the wear much better than the 6. Since we have our own manufacturing facility we can also use a wide variety of materials, that meet the customer’s special needs. We want nothing but the best materials on the cylinder heads we sell to our customers.

3306 Cat Valve Kit

3600 Cat Valve Kit

7042 GSI Kit

7044 Valve Kit

7044 Valve Kite

G3500 Cat Valve Kit

3500 Cat Valve Kit

IR KVG Valve Kit

IR SVG Valve Kit

Superior 825 Valve Kit

CAT spark plug adaptors

Model	Location	Material	Part Number
Part number
Waukesha 145	Intake	Stellite	145436C
Waukesha 145	Exhaust	Stellite	145336A
Waukesha 1197	Intake		123036-L
Waukesha 1197	Exhaust	Stellite	125136-C
Waukesha 3711	Intake		240036
Waukesha 1905	Intake		97236B
Waukesha 1905	Exhaust	Stellite	97336C
Waukesha 7042 GSI	Intake	Stellite	204236K 30 degree
Waukesha 7042 GSI	Exhaust	Inconel	204236M 30 degree
Waukesha GL	Intake	Stellite	204236K 30 degree
Waukesha GL	Exhaust	Inconel	204236L 20 degree
Superior G825	Intake	Stellite	0-23972
Superior G825	Exhaust	Tribaloy	0-23971
Ingersoll SVG	Intake & Exhaust	Stellite	IR13975
Ingersoll KVG	Intake	Stellite	IW15573
Ingersoll KVG	Exhaust	Stellite	IW8956
Ingersoll KVS FT	Intake	Stellite	IR17793
Ingersoll KVS FT	Exhaust	Stellite	IR32558
GUASCOR	Intake & Exhaust	PYROMET 20	1910183B
CAT G3306 S/V	Intake	Inconel	2W2621
CAT G3306 S/V	Exhaust	Inconel	2W2877
CAT G3306 L/V	Intake	Inconel	7W7490
CAT G3306 L/V	Exhaust	Inconel	7W7491
CAT G3400	Intake	Inconel	1227353
CAT G3400	Exhaust	Inconel	1018314
CAT G398 & D398	Intake	Inconel	1W8606
CAT G398	Exhaust	Inconel	2W3211
CAT G398	Intake	Inconel	1W8606
CAT D398	Exhaust	Inconel	1W1822
CAT G3500	Intake & Exhaust	Inconel	1047184
Waukesha 7042GL Adaptors (short)		Stainless	209567E
Waukesha 7042GL adaptors (long)		Stainless	209567K
Waukesha 7042 GL pre-chamber		Stainless	209724F
CAT 3306 spark plug adaptor		Stainless	7N1743
CAT 342 spark plug adaptor		Stainless	7L0917
CAT 398 spark plug adaptor		Stainless	7L0918
7044 IN		STELLITE #12	204336B
7040 EX		INCONEL #12	204336K
G-3600 CAT IN		STELLITE #12	4P2854
G-3600 CAT EX(INCONEL) 319-9074		STELLITE #12	1542417
